Draw with Photoshop Elements 10 Pencil Tool

Drawing with the Pencil tool in Photoshop Elements 10 creates hard edges. You can’t get the soft, feathery edges that you can with the Brush tool. In fact, the edges of a pencil stroke can’t even be anti-aliased.

Keep in mind that if you draw anything other than vertical or horizontal lines, your lines will have some jaggies when they’re viewed up close. But hey, don’t diss the Pencil just yet. Those hard-edged strokes can be perfect for web graphics. What’s more, the Pencil tool can erase itself, and it’s great for digital sketches.


Follow these steps to become familiar with the Pencil tool:

  1. Select the Pencil tool from the Tools panel.

    You can also press the N key. By default, the Pencil tool’s brush tip is the 1-pixel brush. Yes, even though the Pencil tip is hard edged, it is still referred to as a brush.

  2. On the Options bar, choose your desired pencil options, beginning with a brush preset. Click the arrow and select your desired brush from the Brush Preset Picker drop-down panel.

    To load another preset library, click the Brushes menu at the top of the panel.

    Remember that you aren’t limited to the standard old brush strokes. Check out the Assorted and Special Effects brushes found in the Brushes drop-down menu on the Brushes panel. You’ll be surprised by the interesting brushes lurking on these panels. Use them to create standalone images or to enhance your photographic creations.

    Access the menu on the Brushes panel to save, rename, or delete individual brushes and also save, load, and reset brush libraries.

  3. Choose your brush size.

    A preset brush’s pixel diameter is shown as text below a thumbnail image of the brush shape. If you want to change the size of that brush tip, drag the Size slider or enter a value.

  4. Select a blend mode.

    Blend modes alter the way the color you’re applying interacts with the color on your canvas.

  5. If you want the background to show through your strokes, adjust the opacity by dragging the slider or entering an opacity percentage less than 100 percent.

    The lower the percentage, the more the background images show through.

    Your strokes must be on a separate layer above your images for you to be able to adjust the opacity and blend modes after you draw them.

  6. (Optional) Select Auto Erase if you want to enable that option.

    This option removes portions of your pencil strokes. For example, say that your foreground color is black and your background color is white, and you apply some black strokes. With Auto Erase enabled, you apply white if you drag back over the black strokes. If you drag over the white background, you apply black.

  7. Click and drag with the mouse to create your freeform lines.

    To draw straight lines, click at a starting point, release the mouse button, and then Shift-click at a second point.
